TANAMAZ GOLD
TANAMAZ GOLD
PREMIUM STEEL – STANDARD PRICE
TANAMAZ GOLD is a quality coated steel product developed with two options: color-coated steel and cold-rolled steel. Featuring an Al-Zn alloy coating and durable polyester paint system, this product stands out for its corrosion resistance and long-lasting color retention, suitable for both residential and industrial constructions.
Quaranty
PREMIUM STEEL – STANDARD PRICE
TANAMAZ GOLD is a quality coated steel product developed with two options: color-coated steel and cold-rolled steel. Featuring an Al-Zn alloy coating and durable polyester paint system, this product stands out for its corrosion resistance and long-lasting color retention, suitable for both residential and industrial constructions.
Key Features
Product
TANAMAZ GOLD COLOR
TANAMAZ GOLD is a premium coated steel product line developed with two options: colored steel and galvanized steel. Featuring a durable Al-Zn alloy coating and a resilient Polyester paint system, the product stands out for its excellent corrosion resistance and long-lasting color retention, making it suitable for both residential and industrial projects.
Technical Specifications
|
Applicable Standards |
Coating Mass |
Coating Thickness |
Thickness Tolerance |
Mass Tolerance |
Corrosion Resistance Range |
Base Steel Thickness (mm) |
|
JIS G3322, JIS 3312, ASTM 3755, AS 1397, EN 10169, IS 15961 |
AZ50 |
15/5 microns – 4 protective layers | ±0.04 mm | ±0.1 kg/m² | ≥ 5 km | 0.18 – 1.2 |
Jade Green
Warranty Policy
(*) Subject to Tay Nam Steel’s terms and conditions.
(*) Warranty period may vary depending on objective factors such as weather, installation location, and internal usage conditions of the project.
E-profile
TANAMAZ GOLD COLD
TANAMAZ GOLD stands out with a high-quality aluminum-zinc alloy coating, proudly featuring an advanced protective layer that delivers superior corrosion resistance. Its smooth, glossy surface not only enhances the aesthetic value of any project but also endures harsh weather conditions with remarkable durability. Thanks to its excellent strength and anti-oxidation properties, the cold-coated steel helps extend the lifespan of constructions while minimizing maintenance costs.
Technical Specifications
| Applicable Standards |
Coating Weight (Coating Mass) |
Thickness Tolerance |
Weight Tolerance |
Corrosion Resistance Range |
Base Steel Thickness (mm)
|
|
JIS G3321, ASTM A792, AS 1397, EN 10346, SNI 4096, IS 15961 |
AZ100/70 |
±0.04 mm | ±0.1 kg/m | ≥ 5 km | 0.18 – 0.80 |
Color palette
Warranty Policy
(*) Applied according to Tan Nam Steel’s terms and conditions.
(*) Depending on objective conditions such as weather during installation, installation location, and usage environment within the project, the warranty period may vary.
E-profile
TANAMAZ GOLD PIPE
TANAMAZ GOLD pipe is a product made from premium cold-rolled steel, coated with aluminum-zinc or color coating using advanced Korean technology. Thanks to its multi-layer protective structure and the application of advanced Polyester paint system, the product offers outstanding corrosion resistance, oxidation resistance, and durability under pressure.
Especially, the colorfast coating ensures the pipe maintains its glossy, aesthetic appearance for a long time, even in harsh environments such as coastal areas, industrial zones, or regions with tropical monsoon climates.
Technical Specifications
| Coating Thickness | Width | Applicable Standards | Thickness |
|
AZ100 |
57.50 – 1650 mm |
JIS G3323 (Japan) |
0.18 – 1.4 mm |
| Specifications | Round Pipe | Square Pipe | Rectangular Pipe |
|
12.7 – 114 mm |
10 – 100 mm |
10×20 – 60×120 mm |
E-profile
